Flux Core Welding

Flux core welding has become one of the most practical and efficient processes for a wide range of fabrication and repair work.

It offers a combination of portability, high deposition rates, and versatility that benefits both new and experienced welders. From our experience, it performs reliably in challenging environments and handles thicker materials with fewer passes compared to some other processes.

In this article, we explain what flux core welding is, how it works, and where it's most effective. We also outline its advantages and drawbacks, then provide step-by-step tips to help achieve clean, strong welds with consistent results.

What this article covers:

• What Is Flux Core Welding?
• Advantages of Flux Core Welding
• Drawbacks of Flux Core Welding
• Flux Core Welding Process & Tips

What Is Flux Core Welding?

Flux core welding is a semi-automatic or automatic arc welding process that uses a continuously fed tubular wire filled with flux as the electrode. When the wire melts, the flux reacts and produces a shielding gas and a layer of slag to protect the molten weld from contaminants.

It can be self-shielded, where the flux provides all the protection, or dual-shielded, which uses both flux and external shielding gas. What sets flux core welding apart from MIG welding and TIG welding is that the shielding can come directly from the flux inside the wire, allowing for more flexibility in certain conditions.

How Does Flux Core Welding Work?

The process works by feeding the flux-filled wire through a welding gun toward the workpiece. When the arc forms between the wire and the base metal, it melts both, while the flux inside the wire vaporizes to create a shielding atmosphere.

The melted flux solidifies into slag on top of the weld bead, preventing contamination while the weld cools. Once the weld is finished and cooled, the slag is chipped away to reveal the final bead.

IMAGE 2. Alt tag: “flux core weld”

What Is Flux Core Welding Used for?

Similar to stick welding, flux core welding is often used in construction, shipbuilding, pipeline work, heavy equipment repair, and structural fabrication. From our experience, it's especially valuable in outdoor and windy environments where gas-shielded MIG would struggle.

It's also a go-to for thicker materials that need deep penetration, making it ideal for heavy-duty jobs and field repairs.

Advantages of Flux Core Welding

Flux core welding offers several benefits that make it a dependable choice for both shop work and field projects. These strengths come from the process design and the versatility of the equipment:

• Portable, especially for self-shielded wire, which doesn't require gas cylinders.

• High deposition rates and strong penetration for faster welding on thick materials.

• Works on a range of metals, including carbon steel, stainless steel, and some alloys.

• Handles rust, paint, and less-than-perfect prep better than processes like TIG.

• Easier for beginners to learn compared to stick or TIG welding.

• Performs reliably in outdoor or windy conditions where shielding gas would be blown away.

Drawbacks of Flux Core Welding

While flux core welding is effective in many situations, it does come with trade-offs. Understanding these limitations can help prevent common mistakes and improve overall weld quality:

• Slag needs to be removed after welding, adding extra steps.

• Produces more smoke and spatter, which means better ventilation and cleanup are needed.

• Flux core wire can cost more than standard MIG wire.

• Poor setup can lead to defects like porosity or slag inclusions.

• Not well-suited for very thin materials, which are more prone to burn-through.

Flux Core Welding Process & Tips

Getting the best results from flux core welding comes down to technique, preparation, and knowing your machine. These steps are straightforward, but each one has a big impact on weld quality and consistency:

1. Clean Your Metal Properly

Flux core welding can handle some surface contaminants, but that doesn't mean prep work should be skipped. Heavy rust, thick paint, grease, and mill scale all interfere with arc stability and bead appearance. We've tested this on everything from weathered farm equipment to new steel plate, and the difference in results is clear.

A quick pass with a wire brush can help, but a grinder with a flap disc removes deeper contamination. Pay close attention to edges and joints where dirt and rust like to hide.

2. Choose the Right Wire and Settings

When using your welder, the wrong wire or polarity can sabotage an otherwise good weld. For most mild steel projects, E71T-11 has proven reliable for us in both shop and outdoor environments. It runs well without external shielding gas, making it a strong choice for fieldwork.

Always set the machine to direct current electrode negative (DCEN) for self-shielded flux core wire. This setup produces deeper penetration and helps maintain a stable welding arc. If you switch to dual-shielded wire, check the manufacturer's specs since settings may differ.

3. Control Stick-Out and Torch Angle

Stick-out is the length of wire between the contact tip and the workpiece. We've found that keeping it around ½ to ¾ inch gives the arc a balanced, controllable feel. Too short and the arc can become harsh, causing excess spatter. Too long and the arc loses stability, making penetration inconsistent.

We recommend a drag technique with about a 15-degree torch angle in the direction of travel. This allows the slag to trail behind the weld pool, keeping it from contaminating the molten metal.

4. Match Feed Speed and Voltage

Voltage controls heat. Wire feed speed controls how fast filler metal enters the weld pool. Both need to work together. If the wire feed is too fast for the set voltage, the gun may push against the workpiece, creating spatter and uneven beads.

If it's too slow, the arc can cut in and out, leading to poor fusion and weak welds. We adjust settings by running short test beads on scrap until the arc sounds smooth and steady. That short tuning session often saves time later by avoiding rework.

5. Remove Slag Before the Next Pass

Slag protects the weld bead as it cools, but it has no place in the finished joint. We wait until the weld is cool enough to handle, then use a chipping hammer or wire brush to remove the layer completely.

Any slag left behind will get trapped under the next pass, creating voids or inclusions. On multipass welds, we also inspect each bead for cracks or undercut before continuing. Good cleanup ensures every layer fuses properly.

6. Put Safety First

Flux core welding produces bright arcs, hot spatter, and fumes that need to be managed. We always weld in a well-ventilated space or use fume extraction when working indoors.

PPE is also crucial. A quality auto-darkening welding helmet with the correct shade prevents eye strain and protects against arc flash. Heavy welding gloves and a welding jacket keep skin safe from burns and UV exposure. These are non-negotiable in our shop, whether the job lasts two minutes or two hours.

Conclusion

Flux core welding delivers a combination of portability, high deposition rates, and versatility that makes it a practical choice for many welding applications. It works well in outdoor conditions, handles thicker materials with fewer passes, and can tolerate less-than-perfect surface preparation.

The process does require proper setup, attention to technique, and post-weld cleanup to ensure strong, defect-free results. By understanding its advantages and limitations, welders can select the right wire, settings, and approach for each job.
