Types of Welds
Understanding the different types of welds is essential for anyone working in metal fabrication. These weld types determine how strong, durable, and functional a welded structure will be when finished.
In this article, we’ll walk you through the most common types of welds. We’ll also dive into joint weld types and explain where each is typically used and why it matters.
Let’s start with the basic weld types.
What this article covers:
Basic Weld Types
Fillet Weld
Our research indicates that the fillet weld is one of the most commonly used welds in the industry. It’s used to join two pieces of metal at a right angle or in a lap joint configuration, forming a triangular cross-section where the materials meet.
This weld is popular because of its simplicity and strength. You’ll often find fillet welds in structural applications such as connecting beams to columns. They’re also widely used in shipbuilding and the automotive industry because they can handle heavy loads and are quick to apply.
To execute consistent fillet welds with a TIG welder, consider the Lincoln POWER MIG 215 MPi Multi-Process Welder TIG One-Pak. This versatile welder features dual input voltage and an intuitive user interface, making it perfect for general fabrication and repair.
Groove Weld
Groove welds are used when two metal pieces need to be joined in the same plane. This involves preparing the edges to create a groove for the weld to fill. The purpose here is to ensure deep penetration of the weld, which directly contributes to the joint’s strength.
These welds are essential in projects where high stress is a factor, like pipeline systems or the construction of heavy-duty structures. They’re also widely used in pressure vessels and other applications where the integrity of the joint is critical.
Plug Weld
In a plug weld, one piece of metal has a hole, which is filled with weld material to fuse it to the piece beneath it. This technique is a great alternative to using rivets or bolts in sheet metal work.
Plug welds are frequently found in automotive repair and manufacturing because they provide a strong, protrusion-free bond. They’re also valued in aerospace applications, where clean lines and durability are important.
The Forney 190 MIG Welder is a compact yet powerful MIG welder with improved wire feed control, which is ideal for plug welding thin to medium gauge metal.
Slot Weld
Slot welds are quite similar to plug welds, with one key difference: the hole is elongated. This gives the weld more surface area and results in a stronger joint.
You’ll see slot welds in structural applications that require additional strength, like frames for buildings or components in heavy machinery. The elongated shape helps spread out the stress across a larger area, which makes the weld less prone to failure under load.
Based on our observations, the Lincoln POWER MIG 360MP Multi-Process Welder delivers precise amperage and stable arc control that is perfect for spot welding in both industrial and mobile environments.
Flash Weld
Flash welding is a resistance welding process that works by pressing two metal components together and running an electrical current through the joint. The heat generated by the resistance fuses the pieces without filler material.
This technique is especially common in industries that deal with long, continuous metal lengths like railroads or pipelines. It creates strong, uniform welds and is particularly useful when precision and consistency are top priorities.
Our Lincoln Electric Vantage 322 Kubota is a rugged engine-driven welder with multi-process capabilities. It is designed for field work where performance and durability are key.
Spot Weld
Spot welding is another type of resistance welding, but in this case, it focuses the heat and pressure on a small area. The result is a quick, localized weld. Hence the name “spot” weld.
You’ll see this type of welding used extensively in the automotive world. It’s also common in the production of appliances and metal furniture because it’s fast, efficient, and cost-effective for joining sheet metal components.
Seam Weld
Seam welding builds on the principles of spot welding but turns it into a continuous process. Rotating wheel electrodes create overlapping welds that form a sealed seam. This makes it a go-to method when a leak-tight or airtight seal is needed.
Fuel tanks, radiators, and metal containers are just a few examples where seam welding shines. It ensures consistent weld quality and is ideal for components that need to contain liquids or gases without leaks.
Surfacing Weld
Unlike most welds, surfacing welds aren’t used to join parts together. Instead, they add material to the surface of a component, either to restore worn parts or to add a protective, wear-resistant layer.
This technique extends the life of components like rollers, shafts, or valves. It’s also useful for applying hard-facing alloys to parts regularly exposed to abrasion or impact.
Joint Weld Types Explained
Lap Joint Welding
Our findings show that a lap joint is created by overlapping two pieces of metal and welding along the edges where they meet. It’s useful when working with materials of different thicknesses and is often paired with resistance or fillet welding techniques.
This joint is widely used in the automotive and fabrication industries due to its simplicity and ability to distribute stress evenly across the joint. However, one potential drawback is that if it’s not properly sealed, moisture can creep in, leading to corrosion.
Butt Joint Welding
In a butt joint, two pieces of metal are placed edge to edge in the same plane and then welded. It often requires precise alignment and sometimes edge preparation, depending on the material thickness and the type of weld being used.
This joint is critical in applications like pipeline construction, structural steel frameworks, and heavy machinery. For the weld to hold up under pressure and stress, complete fusion and penetration are essential.
Tee Joint Welding
A tee joint forms when one piece of metal is welded perpendicular to another, making a “T” shape. Fillet welds are commonly used in this type of joint due to their compatibility with the right-angle configuration.
You’ll find tee joints in structural applications, such as frame constructions, where vertical and horizontal components need to be joined. Because the configuration can concentrate stress at the intersection, careful welding is necessary to avoid issues like cracking or warping.
The Lincoln POWER MIG 360MP offers advanced control over heat input, ensuring balanced, strong welds in high-stress tee joints.
Edge Joint Welding
Edge joints involve placing two metal sheets side by side so that their edges are adjacent and parallel. These joints are commonly used when you need to reinforce or seal edges.
While edge joints aren’t known for their strength, they do serve specific purposes in tank manufacturing, sheet metal work, and enclosures. They’re useful when the goal is to align and seal rather than carry heavy loads.
Corner Joint Welding
Corner joints are used to join two metal pieces at a 90-degree angle, usually forming an “L” shape. This type of joint is among the most widely used in box construction and sheet metal work.
You’ll find corner joints in everything from frames and enclosures to metal furniture. Depending on the application, these joints can be welded using fillet, groove, or butt welds.
Conclusion
Knowing the various types of welds and joints and understanding when to use each is a key part of success in metal fabrication. Every type, from a simple fillet weld to a more complex flash weld, brings specific strengths to the table.
Whether you’re working on large-scale structural builds, automotive repairs, or intricate industrial components, the right gear can make all the difference.
Visit Bad Ass Welding Products and deliver high-quality results that stand up to real-world demands.
