TWECO (43)

Tweco No. 1 Air Cooled MIG Gun 180 Amp 030-035, Wire Diameter 10FT, 1010-1111 Included Features Fully Assembled, ready to use MIG-Gun Process(es) GMAW Industrial Applications All Semi-automatic air-cooled MIG Welding applications

Tweco No. 1 Air Cooled MIG Gun 180A, 030"-035", 12FT, 1010-1112 Included Features Fully Assembled, ready to use MIG-Gun Process(es) GMAW Industrial Applications All Semi-automatic air-cooled MIG Welding applications

Tweco No. 1 MIG Gun 180 Amp .030"-.035" 12FT, Miller 1010-1133 Replacement Mig gun for Miller Welders Included Features Fully Assembled, ready to use MIG-Gun Process(es) GMAW Industrial Applications All Semi-automatic air-cooled MIG Welding applications

Tweco No. 1 Air Cooled MIG Gun 180A, 030-035, 15FT, Miller Welding Machine Connection 1010-1135  Neoprene insulated quick-change conductor tubes swivels 360 degrees. Enhanced direct plug capabilities. Fully Assembled, ready to use MIG-Gun

Tweco No. 1 Air Cooled MIG Gun 180A, 030"-035", 15FT, Lincoln 1010-1145 Tweco No. 1 Air Cooled MIG Gun 180 Amp Gun, 030"-035", 15FT, Fits Lincoln Welding Machines

Tweco Mig Gun No. 2 Miller Welder Back End, 15 Foot Cable 1020-1134 Industry Standard Metal jacket conductor tube Enhanced direct plug capabilities Fully Assembled, ready to use MIG-Gun

Tweco® Eliminator® Series Standard Duty Contact Tip accommodates 0.045" wire and is perfect for use with 250 - 650 A Tweco® Eliminator® MIG guns. This contact tip is specially made for Eliminator® style MIG guns. 1 1/2" Contact tip has 0.054" ID and 0.345" OD. Contact tip is sold as 25 per pack. KEY FEATURES Patented, extended life consumables designed specifically for eliminator® style mig guns Delivers better conductivity resistance properties Offers increase tip life Reduces micro arcing on the inside diameter surface Machined from a copper alloy tubing providing a consistent and smooth inside diameter surface Twist it and it locks in place No threads to worry about Increased surface contact between contact tip/diffuser for better electrical conductivity Twist it quarter turn clockwise Use genuine Tweco® accessories, parts, and consumables to protect the quality of your welds and the life of your gun When tip wear point is reached after use, twist it half turn counter-clockwise to expose a new wear point This doubles the life of the tip Thick-walled diffuser design acts as a heat sink and conducts heat away from the arc source Increases electrical conductive surface area and thereby increases electrical conductivity Applications Used in heavy duty welding application up to 600 Amp Series EL16 Wire Size 0.045 Inch Tip Bore 0.054 Inch Tip Length 1.5 Inch MIG Gun Model Tweco®; Tweco® Eliminator® Hazardous No Pack 1 Each

Tweco® Coarse Threaded Copper Nozzle with 3/4" bore size is perfect for standard gas diffuser and protects the quality of your welding as well as the life of your gun. 3.25" Nozzle with 0.875" OD making it ideal for use in medium to heavy duty welding application up to 450 A. It features part number rolled stamped on the external surface for easy identification. Nozzle with recess contact tip relationship 0.125-0.156" is made from copper alloy. It has a 3-piece design without an additional insulator includes a nozzle housing, which is cut and formed from 122 DHP copper alloys tubing, a nozzle insert machined from a solid brass and nozzle insulator constructed from silicone material. It has nozzle insert that allows machining of internal threads in order to match the gas diffuser. It features threads on the standard EL gas diffuser. Nozzle offers electrical insulation required from the gas diffuser using the nozzle insulator. Nozzle is sold as 2 per pack. KEY FEATURES Easy identification - part no rolled stamped on the outside surface 3-piece design - does not require an additional insulator Nozzle housing - cut and formed from 122 dhp copper alloy tubing Nozzle insulator - made from g7 silicone material, providing the electrical insulation needed from the gas diffuser Nozzle Insert - machined from a solid brass allow and machining the internal threads to match the gas diffuser Recessed Tips are generally used for higher heat applications where longer electrical stick-out is required, or in cases where the nozzle may touch the work piece (tack, spot, and stitch) Flush Tips are generally used where a shorter electrical stick-out is used sometimes resulting in shorter/tighter arc lengths, This brings the tip closer to the work piece Protruding Tips are generally used when welding open root pipe or any joint that requires the welder to get into a tight weld joint. However the down side to this is the chance of arcing the tip to the work piece, which could damage front end parts resulting in downtime needed to replace Applications Used in medium to heavy duty welding application up to 450 Amp Series EL24CT Tip Bore 3/4 Inch Tip Length 3.25 Inch Tip/Nozzle Relationship Recessed MIG Gun Model Tweco®; Tweco® Eliminator® Hazardous No Pack 1 Each

Tweco® 16RS/S Series Standard Duty Brass Gas Diffuser is perfect for use with slip-on nozzle assemblies with 350 A Tweco® Spray Master® MIG gun series as well as eliminator front-end consumables. Gas diffuser has magnificent electrical properties making it ideal for use in light to medium duty standard welding application up to 350 A. 2.297" Gas diffuser with M11 x 1.5-6g thread size has six 0.094" gas holes. It features part number rolled stamped on the external surface and overall length with replacement O-ring number for easy identification. Gas diffuser is made from 360-brass alloy bar stock offers consistent dimensional stability. It has a proper threaded size conductor tube to be used with MIG guns. It features a silicon O-ring to provide secure sealing against the nozzle assembly. Gas diffuser offers the OD course threads so that the nozzle assembly can come with the conductor tube. Gas diffuser is sold as 5 per pack. KEY FEATURES Easy identification - part no rolled stamped on the outside surface Designed to be used with course thread nozzle assemblies Gas diffuser provides the OD course threads so that the nozzle assembly can attach to the conductor tube Gas diffuser has a silicon o-ring to seal against the nozzle assembly Machined from 360 brass alloy bar stock to ensure consistent dimensional stability Recessed Tips are generally used for higher heat applications where longer electrical stick-out is required, or in cases where the nozzle may touch the work piece (tack, spot, and stitch) Flush tips are generally used where a shorter electrical stick-out is used sometimes resulting in shorter/tighter arc lengths, this brings the tip closer to the work piece Protruding Tips are generally used when welding open root pipe or any joint that requires the welder to get into a tight weld joint However the down side to this is the chance of arcing the tip to the work piece, which could damage front end parts resulting in downtime needed to replace Replacement O-ring Part No EL52-1 (Stock No 1560-1108) Standard Duty M11 x 1.5-6G Male threaded Applications Used in light to medium duty welding application up to 350 Amp Series 16RS; 16S Tip Length 2.297 Inch MIG Gun Model Tweco®; Tweco® 350 Spray Master® Hazardous No Pack 5/Pack

Tweco® Eliminator® Series Brass Gas Diffuser is perfect for use with course thread nozzle assemblies with 600 A Tweco® Eliminator® MIG gun series as well as eliminator front-end consumables. Gas diffuser has magnificent electrical properties making it ideal for use in medium to heavy duty standard welding application up to 600 A. 2.521" Gas diffuser with M12 x 1.5-6g thread size has six 0.094" gas holes. It features conduit liner up to 5/64" wire with a silicon O-ring to provide secure sealing against the nozzle assembly. It features a course thread that is machined on the external surface to let the nozzle assemblies to thread over and accommodate the nozzle in place during the welding process. It features part number rolled stamped on the external surface and overall length with replacement O-ring number for easy identification. Gas diffuser is made from 360-brass alloy bar stock offers consistent dimensional stability. It has a proper threaded size conductor tube to be used with MIG guns. Gas diffuser is sold as 5 per pack. KEY FEATURES Easy identification - part no rolled stamped on the outside surface Designed to be used with course thread nozzle assemblies Machined from 360 brass alloy bar stock to ensure consistent dimensional stability Gas diffuser provides the od course threads so that the nozzle assembly can attach to the conductor tube Gas diffuser has a silicon O-ring to seal against the nozzle assembly Replacement O-ring Part No EL52-1 (Stock No 1560-1108) Recessed Tips are generally used for higher heat applications where longer electrical stick-out is required, or in cases where the nozzle may touch the work piece (tack, spot, and stitch) Flush Tips are generally used where a shorter electrical stick-out is used sometimes resulting in shorter/tighter arc lengths, this brings the tip closer to the work piece Protruding Tips are generally used when welding open root pipe or any joint that requires the welder to get into a tight weld joint However the down side to this is the chance of arcing the tip to the work piece, which could damage front end parts resulting in downtime needed to replace Applications Used in medium to heavy duty welding application up to 600 Amp Series 14H; M12 Wire Size 0.078 Inch Tip Length 2.521 Inch MIG Gun Model Tweco®; Tweco® 450 Eliminator® Hazardous No Pack 5 Each

Description Contact Tip, EL16, Wire Size: 0.035 Inch; Tip Bore: 0.044 Inch; Tip Length: 1.5 Eliminator EL16-35 Contact Tip (035) - 25 Per Pack Tweco® Eliminator® Series Contact Tip accommodates 0.035" wire and is perfect for use with 250 - 650 A Tweco® Eliminator® MIG guns. 1 1/2" Contact tip has 0.044" ID and 0.345" OD. This patented contact tip with extended life is specially made for Eliminator® style MIG guns. KEY FEATURES 0.035 in wire size Use with Tweco®, Tweco® Eliminator® MIG guns Patented, extended life consumables designed specifically for eliminator® style MIG guns

Tweco 11 Series .040" Contact Tip Tweco - 11-40 CONTACT TIP1110-1103

Tweco - 11H-45 CONTACT TIP .045" 25 Pack 1110-1204  Easy identification - Each contact tip is marked showing Part No. and wire diameter Excellent electrical properties Inside diameter tolerance is held to +/-.003; Machined from a copper alloy tubing providing a consistant and smooth inside diameter surface Threaded style contact tip to ensure proper contact with a gas diffuser when installed to the MIG gun Used in standard welding application up to 300 amperes

Tweco 11 Series Tapered Contact Tip .023" Wire Diameter Tweco - 11T-23 CONTACT TIP 1110-1300

Tweco - 11T-30 CONTACT TIP .030" Tapered - 25 Pack 1110-1301 Easy identification - Each contact tip is marked showing Part No. and wire diameter Excellent electrical properties Inside diameter tolerance is held to +/-.003; Tapered tip Machined from a copper alloy tubing providing a consistant and smooth inside diameter surface Threaded style contact tip to ensure proper contact with a gas diffuser when installed to the MIG gun Used in standard welding application up to 200 amperes
